Purdue University Space Program students select A6061-RAM2 for TADPOLE propulsion system

April 4, 2024

PSP-AC’s propulsion team  with the build of their TCA component (Courtesy Purdue University)
PSP-AC’s propulsion team with the build of their TCA component (Courtesy Purdue University)

A team of fifty undergraduate students on Purdue University’s Active Controls team have used Additive Manufacturing to advance vertical take-off and vertical-landing (VTVL) technology. The Purdue Space Program-Active Controls (PSP-AC) team is under an umbrella student organisation on Purdue University’s campus that aims to empower students to innovate in space exploration. Their current project satisfies the milestones of the Collegiate Propulsive Lander Challenge (CPLC), which has challenged student teams to create self-landing rockets. The challenge gave rise to PSP-AC’s TADPOLE propulsion system.

“This team operates under a greater vision to prepare the current and future classes of engineers to be more attuned to the current technological trends in space exploration,” stated Pavit Hooda, PSP-AC project manager and co-founder.

THE WORLD OF METAL AM TO YOUR INBOX
Subscribe to our weekly newsletter
Sign up

The TADPOLE propulsion system is part of PSP-AC’s journey of creating a bipropellant hopper vehicle. Such a vehicle requires a propulsion system with long burn times, a regenerative cooling circuit, and thrust vector control capabilities. To produce a thrust chamber assembly (TCA) that can achieve these extreme specifications with complex geometries and precise tolerances, PSP-AC chose Elementum 3D to manufacture the aluminium combustion chamber, cooling circuit, and nozzle in a single component using Laser Beam Powder Bed Fusion (PBF-LB).

“We are honoured to offer our team’s AM knowledge, expertise, and technology to inspire all the students involved in the Purdue Space Program to push the limits of conventional thinking and print the first ever A6061-RAM2 thrust chamber assembly,” said Dr Jacob Nuechterlein, Elementum 3D founder and president.

PSP-AC's Alex Suppiah (left), Yash Amin (centre), and Andrew Radulovich (right) discuss the AM part (Purdue University)
PSP-AC’s Alex Suppiah (left), Yash Amin (centre), and Andrew Radulovich (right) discuss the AM part (Purdue University)

At a chamber pressure of 250 psi and a thrust class of 550 lbf, PSP-AC determined that Elementum 3D’s advanced RAM technology was necessary for making this project a reality. The aluminium alloy A6061-RAM2 material provides the proper yielding characteristics required for the operating conditions of TADPOLE and offers an extended lifespan to the TCA enabling the team to include more tests in their test campaign, ultimately allowing them to learn more from this experience of designing and testing a propulsion system.

PSP-AC selected aluminium to build the thrust chamber assembly because of its great thermal properties, light weight, and low cost. The team was enthusiastic to discover Elementum 3D’s aluminium alloy does not have the drawbacks that were found with other AM aluminium powders, such as rough surface finish. The thrust chambers manufactured with A6061-RAM2’s had a very smooth surface finish, which is good for heat transfer and better thermal and mechanical properties than the competing alloys.

Another challenge of Additive Manufacturing a TCA is the post-processing and depowdering of the internal channels. The PSP-AC team worked very closely with Elementum 3D engineers to develop viable solutions and dimensions to allow for adequate powder removal. The team found it generally easier to depower than the industry standard GR-COP alloys, which is a big advantage. Additionally, the PSP-AC team reportedly enjoyed working closely with Elementum 3D’s engineers to get detailed material property information on the alloy, which was something they struggled to get from other vendors. This allowed them to understand and model the performance and functionality of the TCA and ultimately compare to experimental data generated during engine testing.

“The whole process is a great engineering challenge and learning experience that was made possible by Elementum 3D’s support. PSP-AC will use these simulations and experimental results to design their next engine,” said Andrew Radulovich, PSP-AC chief engineer.

www.elementum3d.com/

www.purdue.edu/
